Which fork brands and damper systems are compatible with the Universal 8mm + 10mm Fork Shaft Clamp?

The Universal 8mm + 10mm Fork Shaft Clamp is compatible with nearly all modern mountain bike forks that use 8mm or 10mm small shafts, including Fox (FIT, GRIP, Charger, Dorado), RockShox, Marzocchi (Bomber, Mezzer), Manitou, and Cane Creek. The 8mm clamp handles most damper shafts and compression needles; the 10mm clamp fits most air spring shafts and many damper shafts. Note that a separate damper body clamp is still required for a full teardown of GRIP and Charger dampers.

How does the Universal 8mm + 10mm Fork Shaft Clamp differ from single-size shaft clamps?

Single-size shaft clamps cover only one shaft diameter, so a technician servicing a range of forks needs multiple individual clamps. The Universal combo includes both an 8mm and a 10mm clamp in one purchase, covering damper shafts, compression needles, and air spring shafts across virtually all major fork brands. For Fox-specific builds that also require a damper body clamp, Shockwave offers dedicated Fox FIT or GRIP combo sets that bundle all three clamps.

What is the correct way to prepare a shaft before using the Universal 8mm + 10mm Fork Shaft Clamp?

Always clean the shaft with isopropyl alcohol first, then wrap it once in a paper towel before clamping. Select the correct clamp size — 8mm or 10mm — that matches the shaft being worked on. Skipping cleaning or using the wrong clamp size risks shaft damage and is covered in the product's usage guide.

How much does the Universal 8mm + 10mm Fork Shaft Clamp cost, and does Shockwave Parts ship it to Canada?

The Universal 8mm + 10mm Fork Shaft Clamp is priced at $33.49 CAD and is currently in stock. Shockwave Parts ships from Canada; tracked shipping within Canada starts at $8.49 with a maximum of $14.99, and orders over $89 CAD qualify for free Canadian shipping. Orders are processed and dispatched within 1 business day.

What additional tools does Shockwave recommend pairing with the Universal 8mm + 10mm Fork Shaft Clamp for a complete fork service?

For a full lower-leg service, Shockwave recommends pairing this clamp combo with either the Basic Damper Shaft Driver or the Deluxe Damper Shaft Driver, plus a Rebound Driver and Spare Tips (3-Pack). Fox damper top caps require a 6-in-1 top cap wrench, while RockShox damper top caps typically open with a cassette tool. Most forks use 20wt oil in the lowers and 4wt or 5wt oil in the damper; Slickoleum or SRAM Butter is recommended for greasing — not Vaseline.

1 3

Shockwave Parts

Universal 8mm + 10mm Fork Shaft Clamp

$29.00 CAD

Sale Sold out sorry :(

Shipping calculated at checkout.

Universal 8mm + 10mm Fork Shaft Clamp Combo

The most versatile shaft clamp combo for air and damper shafts, fits almost every modern fork including Fox, RockShox, Marzocchi, Manitou, Cane Creek, and more.

Working with long shafts? The Angled 20° 8mm + 10mm Combo is the same tool tilted 20° so shafts clear the center of the vise. Same price.

I added a picture of me threading a 10mm rebound assembly into a FIT RC2 damper.

⚠️ Safety Warning (Read Before Use)

Always:

Clean shaft with isopropyl alcohol
Wrap once in paper towel
Use the correct clamp size (8mm or 10mm)

Usage guide: How to Clamp Small Shafts

What It Does

8mm clamp fits most damper shafts and compression needles
10mm clamp fits most air spring shafts and many damper shafts
Perfect for oil changes, bushing inspection, damper shaft teardown
Works on FIT, GRIP, Charger, Dorado, Bomber, Mezzer, etc.

Compatibility Notes

Fits nearly all forks using 8mm or 10mm small shafts
A damper body clamp is still required for full teardown (GRIP, Charger)
RockShox damper top caps typically open using a cassette tool
Fox damper top caps require a 6-in-1 top cap wrench

Oil & Grease Suggestions

Most forks use:

20wt oil in the lowers
4wt or 5wt oil in the damper

Always use Slickoleum / SRAM Butter, never Vaseline.

Recommended Extras

Disclaimer

Use at your own risk. For home use only. Always clean and prep shafts before clamping.
