Shockwave Parts
Fox GRIP Damper + Air Shaft Rebuild Kit
Fox GRIP Damper + Air Shaft Rebuild Kit
Regular price
$85.49 CAD
Regular price
Sale price
$85.49 CAD
Unit price
/
per
Shipping calculated at checkout.
Couldn't load pickup availability
Β Fox GRIP Damper + Air Shaft Full 200h Rebuild Kit
Complete 200-hour rebuild kit for Fox forks using GRIP dampers. Includes everything needed for damper rebuild and air shaft service, plus drivers, bullet tool, and dust wiper press.
Compatible with GRIP 1 / 2 / 2 VVC / X / X2 dampers, and Fox 32, 34, 36, and 38 forks with FLOAT NA or NA2 air shafts.
Β This rebuild kit is for forks that are not taper-cast. Taper-cast models may not be compatible with the air shaft driver tool.
External Rebuild Guides & Kits:
- Official FOX GRIP Damper Rebuild Guide
- MTB-Hydraulics GRIP Seal Kit (ships in letter mail!)
- MTB-Hydraulics Air Spring Seal Kit(ships in letter mail!)
What's Included:
- 2-in-1 GRIP Clamp Kit:
- 10mm Shaft Clamp (GRIP damper shaft + air shaft)
- GRIP Damper Body Clamp
- Dust Wiper Seal Press Tool
- Basic Damper + Air Shaft Driver
- Float NA/NA2 Plastic Bullet Tool (works with all 10mm Fox air shafts)
Optional upgrade: Real Metal Bullet Tool
Oil Info:
- Use Fox 4wt fluid in damper and on damper-side lowers
- Use Fox 20wt Gold or Motorex Supergliss on the air shaft and air-side lowers
- Use Slickoleum, SRAM Butter on all seals, orings, dust wipers, Bushings in the lowers, etc.
- Use Fox 4wt fluid in damper and on damper-side lowers
- Use Fox 20wt Gold or Motorex Supergliss on the air shaft and air-side lowers
- Use Slickoleum, SRAM Butter on all seals, orings, dust wipers, Bushings in the lowers, etc.
References:
β οΈ Warnings:
- Do not use an adjustable wrench : always use a 26β28mm chamferless socket
- Clean shafts with alcohol before clamping
- Clamp only in correct flat zones, never on threads or logos
- Do not open the GRIP compression assembly unless it's leaking
- Do not use an adjustable wrench : always use a 26β28mm chamferless socket
- Clean shafts with alcohol before clamping
- Clamp only in correct flat zones, never on threads or logos
- Do not open the GRIP compression assembly unless it's leaking
Β
Β Pro Tips
- Fully open rebound and compression before bleeding, or it wonβt work
- Only disassemble the GRIP compression/mid-valve if they leak, they last forever otherwise
- This clamp kit works for GRIP, FIT4 (10mm shaft, not damper tube), FIT RC2 and most air shafts (Only Cane creek uses 8mm air shafts).
- Never insert the damper shaft fully after the bleed is done, always leave 2-3cm from the top when stroking or the damper will lose some oil and not have enough oil inside.
- Grease the Dust Wiper Seals insides and the lower leg bushings generously with SRAM Butter.
Disclaimer: This is a DIY home toolkit. No guarantee of compatibility with taper-cast forks. Always read fork markings and verify air shaft and damper type before opening. To be certain, you can enter the serial number in for Website. See Terms of Service.
